Borehole Cross Over Kits

The purpose of the Borehole Intersection kit is a quick response/lightweight unit as an alternative to current bulky, time consuming alternatives. The system visa use of either readily available compressed air or water can pump up in a matter of seconds its unique flow through valve, stopping the leakage of mine gases into the mines workings.

These gases are then redirected via a series of hoses and values to another unit located in the adjacent mine wall, and mining practices can commence safely in a fraction of the time of standard practices of the past.

Features/ Specs

• Easy to install
• Lightweight
• Quick response time
• Nominal Pipe Size: 4″ – 8″
• Req Inflation Pressure: 30PSI
• Maximum Back Pressure: 15PSI
• Dimensions: 1200mm x 100mm
• Weight: <10kg

Applications

• Coal Mining
• Hard Rock Mining
• Tunneling
• Civil
